PRAZI
II APOLLO D6000 SERIES PRECISION LATHE & ACCESSORIES #98015 |
| Part
Number |
Description
|
List Price |
Our
Price |
Buy
Now |
| D6000 |
Prazi
II Apollo High Precision 10" x 24" Lathe Inch Version.
Includes:
5" 3 Jaw Chuck Inside and Outside Jaws, Compound Rest, 4 Way Turret Tool Post, MT2 Dead Center,
Rohm Drill Chuck (3mm to 13mm) with Arbor, Clear Plastic Safety Guard with Limit Switch,
On/Off Safety Switch, Power Longitudinal Feed, Complete Set of End Gears (Inch/metric threads),
Operations and Parts Manual, Wrenches, Grease Gun, 110V Electrics (220V 1 PH available). Safety Overload Switch,
Emergency Stop Button, Infinitely Variable Spindle Speeds 45-2300 RPM with 1 HP Motor.
Net weigh 330 Lb. (Metric Available #D600EM)
Description:
toolmaker's accuracy with test report
with massive prismatic cast iron bed
with electronically adjustable motor 45 - 2300 r.p.m., equipped with a dynamic speed-adjustable main drive motor which can be adjusted by means of potentionmeter over a wide range of cutting speed
with a single-phase series commutator motor in parallel flow quality with permanent number of revolutions super vision
main spindle bore Ø 20 mm
precision chuck
fixed lathe center MT2
tumbler gear for metric and imperial thread
10 change gears for 12 metric and 12 imperial threads
2 automatic advances/main spindle drive
emergency OFF
Centre distance 600 mm
Centre height 135 mm
Power 1,4 kW, 230 V,50 Hz
Spindle speed r.p.m. 45-2300
Spindle bearing 20 mm optional 30 mm
Cone in spindle nose MT3
Ø-of chuck work 170 mm
Cross slide 140 mm
Longitudinal 60 mm
Swivel-feature of the upper slide rest 360º
Height of turning tools max. 20 mm
Truth of rotation of spindle nose 0,005 mm
Cylindrical turning to 100 overhang 0,01 mm
Ø of chuck work, measured above the guiding bars 270 mm
Tail spindle's range of displacement 65 mm
Lateral displacement of the tailstock +-10 mm
Automatic advance 0,085 optional 0, 16 mm
Thread pitch
Metric thread
Inch thread
0,4-3,0 mm
10-32 G/"
Dimensions of the machine 1215x500 mm
Weight net (without packing) 150 kg
Weight gross (with packing) 175 kg
|
$6,495.00 |
$6,250.00 |
 |
| D6000LMC |
Prazi II Apollo Lathe Mill
Combo Special Inch Version
Includes Adaptor Boot, and Mill Table |
8,495.00 |
7,475.60 |
|
| F2000-06 |
Prazi II Mill Attachment Inch
Version MT2 (Includes Adaptor
Boot) |
2,095.00 |
1,843.60 |
|
| P6L-001 |
Center Drill 5 Pc. Set (#1,
#2, #3, #4, #5 Sizes) |
10.95 |
9.65 |
|
| P6L-002 |
Swivel Head Knurling Tool
with Knurls |
29.50 |
25.95 |
|
| P6L-003 |
Master Drill 116 Pc. Set
Complete (1/16" through 1/2" with A To 2 Sizes Included) |
98.00 |
86.25 |
|
| P6L-004 |
End Mill Deluxe 6 Pc. Set
(1/8", 3/16", 1/4", 5/16", 3/8", 1/2" Dia.) |
49.50 |
43.55 |
|
| P6L-005 |
Carbide Insert Type Tool
Holder 5 Pc. Set |
79.00 |
69.50 |
|
| P6L-006 |
Carbide Inserts (Specify C-2
or C-6 Grade) |
5.95 |
5.25 |
|
| P6L-007 |
Lathe Dogs 3 Pc. Set
(1/2", 3/4" and 1" Sizes) |
24.95 |
21.95 |
|
| P6L-008 |
12 Piece Brazed Carbide Tool
Bit 12 Pc. Set |
49.50 |
43.55 |
|
| P6L-009 |
Boring Bar Set 9 Pc. with
Carbide Brazed Tip |
49.00 |
43.10 |
|
| P6L-010 |
0 - 3/8" Keyless Super
Precision Drill Chuck with Arbor |
119.00 |
104.70 |
|
| P6L-011 |
0 - 3/8" Key Type Super
Precision Drill Chuck with Arbor |
89.00 |
78.30 |
|
| P6L-011-1 |
0 - 1/2" Key Type Super
Precision Chuck with Arbor |
119.00 |
104.70 |
|
| P6L-012 |
High Precision Live Center
(.0001" Accuracy) |
75.00 |
66.00 |
|
| P6L-013 |
Standard Precision Live
Center |
49.00 |
43.10 |
|
| P6L-014 |
Face Plate Slotted (for Flush
Chuck Lathe Work) |
N/A |
179.00 |
|
| P6L-015 |
Turning Between Centers
Attachment |
N/A |
139.00 |
|
| P6L-016 |
5" 4 Jaw Independent Chuck (Includes Special Adaptor Plate) |
295.00 |
259.60 |
|
| P6L-017 |
5" Adaptor Plate for
D6000 Lathe |
149.00 |
131.10 |
|
| P6L-018 |
Quick Change Tool Post Set
(Includes 3 ea. Turning and Facing Plate) |
N/A |
319.00 |
|
| P6L-020 |
Angle Plate with T-Slotted
Milling Table (For Drilling & Milling without F200 Mill Attachment) |
195.00 |
171.60 |
|
| P6L-021 |
Deluxe Metal Floor Stand (Two
Pedestal Bases/ With Locking Cabinet) |
699.00 |
615.10 |
|
| P6L-023 |
Portable Coolant System (Mist
Spray) |
129.00 |
113.50 |
|
| P6L-024 |
5-C Collect Closure for D6000
Lathe Front Mount Key Type (Includes Special Adaptor) |
695.00 |
611.60 |
|
| P6L-025 |
5-C Lever Operated Front
Mount Collect Closure |
N/A |
1145.00 |
|
| P6L-026 |
5-C Collect 8 Pc. Economy
Standard Precision Set (1/8" to 1" by 1/8" Increments) |
75.00 |
66.00 |
|
| P6L-026-1 |
5-C Collect 8 Pc. Precision
Set (1/8" to 1" by 1/8" Increments) |
199.00 |
175.10 |
|
| P6L-027 |
Complete Set of Change Gears
(Inch, Metric Threads) |
CALL |
CALL |
|
| P6L-028 |
Individual Gears for Select
Inch/Metric Threads |
CALL |
CALL |
|
| P6L-029 |
Special Draw Bar Collect
Attachment (For Precision Collects) |
199.00 |
175.10 |
|
| P6L-029-1 |
Individual Precision Collects
(1, 1.5, 2, 2.5 mm) |
59.00 |
51.90 |
|
| P6L-092-2 |
Individual Precision Collects
(3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14 mm) |
39.00 |
34.30 |
|
| P6L-030 |
Fixed Steady Rest |
CALL |
CALL |
|
| P6L-031 |
Traveling Steady Rest |
N/A |
189.95 |
|
| P6L-032 |
T-Slotted Mill Table for
Prazi II D6000 Apollo - Series Lathe/Mill Combo |
CALL |
CALL |
|
| P6L-033 |
Special Adaptor Boot (for
D6000 Lathe and F2000 Series Round Column Mill Attachment |
CALL |
CALL |
|
| P6L-034 |
Mini Milling Machine Vise
(T-Slot Mounted) |
29.95 |
26.35 |
|
| P6L-035 |
Precision Toolmakers Vise |
119.00 |
104.70 |
|
| P6L-036 |
Angle Drilling & Milling
Vise, 2 1/2" Cap. (T-Slot Mounted with Swivel Base) |
65.00 |
57.20 |
|
| P6L-037 |
Precision Boring Head with
Arbor, MT2 |
195.00 |
171.60 |
|
| P6L-038 |
Rotary Table, Low Profile
6" Capacity (Horizontal and Vertical Combination) |
385.00 |
338.80 |
|
| P6L-039 |
Dividing Plate Set (for
P6L-038 H&V Rotary Table) |
165.00 |
145.20 |
|
| P6L-039-1 |
6" Tailstock (for
P6L-038 H&V Rotary Table) |
189.00 |
166.30 |
|
| P6L-040 |
Dividing Head 6" plus
5" 3 Jaw Precision Chuck Combination (With 3 Dividing Plates & Tailstock) |
695.00 |
611.60 |
|
| P6L-041 |
Spare Replacement Multi
Ribbed Belt Z120xXL1037 |
12.95 |
11.40 |
|
| P6L-042 |
Spare Replacement Multi
Ribbed Belt Z140xL037 |
14.95 |
13.15 |
|
| P6L-043 |
Spare Replacement Multi
Ribbed Drive Main Belt J8-559 |
22.95 |
20.20 |
|
| P6L-044 |
Apollo Series F1200-F1210
Mill Operations Manual & Complete Parts List (See Prazi II Mill List) |
9.95 |
8.75 |
|
| P6L-044-1 |
Apollo Series Lathe
Operations Manual and Complete Parts List (D6000 Model) |
9.95 |
8.75 |
|
| P62-042 |
ER-25
Super Precision Chuck and Spanner Wrench (MT2 Only) |
$179.00 |
$157.50 |
|
| P62-043 |
ER-25 Individual Collects
(Specify Exact Size of Inch/Metric Collects) |
CALL |
CALL |
|
| P62-044 |
Ind. Collect Size, Inch
(3/64, 1/16, 5/64"), Metric (1.5 to 2.0mm) |
42.95 |
37.80 |
|
| P62-045 |
Ind. Collect Size, Inch
(3/32", 7/64"), Metric (2.0 to 3.0mm) |
33.95 |
29.90 |
|
| P62-046 |
Ind. Collect Size,
Inch(1/8", 9/64", 5/32"), Metric (3.0 to 4.0mm) |
33.95 |
29.90 |
|
| P62-047 |
Ind. Collect Size, Inch
(11/64", 3/16"), Metric (4.0 to 5.0mm) |
33.95 |
29.90 |
|
| P62-048 |
Ind. Collect Size, Inch
13/64", 7/32", 15/64"), Metric (5.0 to 6.0mm) |
33.95 |
29.90 |
|
| P62-049 |
Ind. Collect Size, Inch
(1/4", 17/64"), Metric (6.0 to 7.0mm) |
33.95 |
29.90 |
|
| P62-050 |
Ind. Collect Size, Inch
(9/32", 5/16") , Metric (7.0 to 8.0mm) |
33.95 |
29.90 |
|
| P62-051 |
Ind. Collect Size, Inch
(21/64", 11/32"), Metric (8.0 to 9.0mm) |
33.95 |
29.90 |
|
| P62-052 |
Ind. Collect Size, Inch
(23/64", 3/8"), Metric (9.0 to 10.0mm) |
33.95 |
29.90 |
|
| P62-053 |
Ind. Collect Size, Inch
(13/32", 27/64"), Metric (10.0 to 11.0mm) |
33.95 |
29.90 |
|
| P62-054 |
Ind. Collect Size, Inch
(7/16", 15/32"), Metric (11.0 to 12.0mm) |
33.95 |
29.90 |
|
| P62-055 |
Ind. Collect Size, Inch
(31/64", 1/2"), Metric (12.0 to 13.0mm) |
33.95 |
29.90 |
|
| P62-056 |
Ind. Collect Size, Inch
(33/64", 17/32", 35/64"), Metric (13.0 to 14.0mm) |
33.95 |
29.90 |
|
| P62-057 |
Ind. Collect Size, Inch
(9/16", 37/64"), Metric (14.0 to 15.0mm) |
33.95 |
29.90 |
|
| P62-058 |
Ind. Collect Size, Inch
(19/32", 39/64", 5/8"), Metric (15.0 to 16.0mm) |
33.95 |
29.90 |
|
| P62-059 |
ER-25 Inch Collect Set, 5 Pc.
(1/8", 3/16", 1/4", 3/8", 1/2" Sizes) |
165.00 |
145.20 |
|
| P62-060 |
ER-25 Master Collect Set 15
Pc. (Inch 3/64" to 5/8") (Metric 1.5 to 16.0mm) |
460.00 |
404.80 |
|
| P62-007 |
End Mill Adaptor (3/8, Bore
MT2 Shank) |
39.50 |
34.75 |
|
| P62-008 |
End Mill Adaptor (1/2",
Bore MT2 Shank) |
39.50 |
34.75 |
|
| P62-009 |
Jeweler Slitting Saw 9 Pc.
Set 2" Saw Blade Diameter (Includes Arbor) |
99.00 |
87.10 |
|
| P62-010 |
Jeweler Slitting Saws
(Individual Sizes) |
8.95 |
7.90 |
|
| P62-011 |
Jeweler Slitting Saw Arbor
(1/2" Shank Holds All 3/8" Hole Size Saws) |
29.95 |
26.35 |
|
| P62-012 |
Fly Cutter Set 3 pc.
(3/4", 1 1/8", 1 1/2" Diameter) |
39.00 |
34.30 |
|
| P62-013 |
Sensitive Drill Feed
Attachment (For Drilling Smaller Diameter Holes) |
79.50 |
69.95 |
|
| P62-014 |
Sensitive Feed Attachment and
Precision Drill Chuck Comination |
119.00 |
104.72 |
|
| P62-036 |
T-Nut & Stud Set
(Includes 4 each T-Nut, Stud and Flange Nut) |
38.95 |
34.30 |
|
| P62-037 |
Deluxe Combination Set
(T-Nut & Stud Set and Clamp & Step Block Set) |
79.50 |
69.95 |
|
| P62-070 |
Special Threaded Draw Bar (Inch Mount Tools 3/8" - 16" Used on F2000 Mill Attachment) |
29.95 |
26.35 |
|
| P62-071 |
Special Threaded Draw Bar (Metric Mount Tools Used on F2000 Mill Attachment) |
29.95 |
26.35 |
|
